Axis P1224-E Miniature HDTV Network Camera 0654-001
Installation Accessories:
- Mounting kit
- Installation guide
- Installation and management software CD
- Windows decoder 1-user license
- AVHS authentication key
Axis P1224-E User Manual
Axis Assigning IP Address User Manual
Axis Product Comparison Table
Axis Product Guide
Product Datasheets
Axis P1224-E Miniature HDTV Network Camera 0654-001 Datasheet (0.90MB)
- Easy and flexible installation
- HDTV 720p
- Edge storage
- Power over Ethernet
- Covert
| Weight | 359.000000 |
|---|---|
| Image chip size | 1/4" |
| Image chip type | Progressive Scan RGB CMOS |
| Image Compression | H.264 (MPEG-4 Part 10/AVC) & MJPEG |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | Colour |
| POE built-in | Yes |
| POE Class | Class 2 (3.84-6.49W) |
| Max. Resolution | 1280 X 720 |
| Supply Volts | 8-28V DC or PoE |
| Lens Mount | fixed focus |
| Viewing Angle | 145° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | < 1 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Warranty | 3 Years |
| Launch Date | May 2014 |
