Axis Q1645 2MP Network Camera with i-CS Lens 01222-001
Packed with intelligent features such as Axis Motion Guard, Axis Fence Guard and Axis Loitering Guard analytics this camera is able to facilitate smart decision-making, enhanced security, first class image usability and fast and easy installation.
Not only this but i-CS lens technology enables fast and easy installation and adjustment, with the ability to adjust the zoom remotely and the camera automatically setting the focus time and money spent on installation can be minimised.
The Q1645 has three scene profiles for users to choose between. With each profile the camera will automatically optimise exposure time, white balance, aperture, sharpness, contrast and noise to suit each specific scenario.
Users can choose between:
- Forensic profile, for general surveillance and capturing details
- Live profile, for more vivid colours and higher contrast
- Traffic overview profile, optimised for traffic surveillance
Included Camera Accessories:
- Stand
- Connector kit
- Resistorx T20 tool
- Installation guide
- Windows decoder 1-user license
Please contact us for stock levels, this camera may have a 10-14 day lead time for delivery.
Axis Q1645 User Manual
Axis Q1645 Installation Guide Axis Assigning IP Address User Manual Axis Product Comparison Table Autumn 2016 Axis Product Guide
Product Datasheets
Axis Q1645 2MP Network Camera with i-CS Lens 01222-001 Datasheet (0.34MB)
- 1/2" sensor
- Forensic WDR and Lightfinder
- Electronic image stabilisation (EIS)
- Axis Motion Guard and Axis Fence Guard
| Weight | 950.000000 |
|---|---|
| Image chip size | 1/2" |
| Image chip type | Progressive Scan RGB CMOS |
| Image Compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG |
| Audio | Two-way |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | Colour/Mono switching |
| POE built-in | Yes |
| POE Class | Class 3 (6.49-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.004 |
| Supply Volts | 8-28V DC or PoE |
| Lens Mount | CS |
| Lens Focal Length | 3.9~10mm |
| Viewing Angle | 109° ~ 42° Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Max. Images per second | 100 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max 9.5W |
| Warranty | 3 Years |
| Launch Date | Spring 2018 |
