Axis Q3505-VE 22mm Fixed Dome Network Camera 0619-001
This product is now End of Life.
May we recommend the Axis Q3505-VE MKII or please feel free to browse our Axis category to find an alternative model.
The Axis Q3505-VE is an outdoor fixed dome network camera with an IK10+ impact resistance and IP66 rating. This camera is vibration and shock resistant with an electronic image stabilisation capability ensures steady video in environments that are subject to vibrations. The Q3505-V is ideal for high-security applications in areas such as cities, airports, railway stations and industrial and critical infrastructure facilities.
Included Accessories:
- Installation guide
- Installation and management software CD
- Windows decoder 1-user license
- Mounting bracket
- Drill hole template
- Cable gaskets
- Resistorx T20 L-key
- I/O connector
- Weather shield
- Axis U-shape conduit adapter
Axis Q3505-VE User Manual
Axis Q3505-VE Installation Guide
Axis Product Comparison Table Autumn 2016
Axis Product Guide
Product Datasheets
Axis Q3505-VE 22mm Fixed Dome Network Camera 0619-001 Datasheet (0.63MB)
- Seamless transition between WDR and Lightfinder
- Axis' electronic image stabilisation
- IK10+ outdoor models
- Efficient, versatile installation
| Weight | 1800.000000 |
|---|---|
| Image chip size | 1/2.8" |
| Image chip type | Progressive Scan RGB CMOS |
| Image Compression | H.264 (MPEG-4 Part 10/AVC), H.264 baseline & main profile, & Motion JPEG |
| Audio | Two-way |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 3 (6.49-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.56 |
| Supply Volts | POE only |
| Lens Mount | vari-focal lens |
| Lens Focal Length | 9~22mm |
| Viewing Angle | 33° ~ 16° Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | Yes |
| Max. Images per second | 50 |
| PSU included | Yes |
| ONVIF Compatible | Yes |
| Power Consumption | max 11.4W |
| Warranty | 3 Years |
| Launch Date | August 2014 |
