Axis Q3515-LV 22mm Fixed Dome Network Camera 01044-001
The Axis Q3515-LV is a fixed dome vandal resistant camera that has been designed for demanding locations.
This camera provides unparalleled video quality in any light condition thanks to its high quality image sensors and features such as:
- Forensic WDR ~ is the latest and most advanced WDR technology reducing visible noise and artifacts to deliver video tuned for maximum forensic usability
- Lightfinder technology ~ has extreme light sensitivity to give more life-like colours in low light conditions.
- OptimisedIR illumination ~ ~ is based on new, smart, power-efficient and patented LED technology, resulting in high-quality and low noise video.
Featuring Axis Zipstream Technology which preserves important details in full image quality whilst reducing storage and bandwidth by 50% or more.
Included Accessories:
- Installation guide
- Windows decoder 1-user license
- Drill hole template
- Cable gaskets
- I/O and DC connectors
- Connector guard
- Resistorx T20 L-Key
- Mounting bracket
Axis Q3515-LV 22mm User Manual
Axis Q3515-LV 22mm Installation Guide Axis Assigning IP Address User Manual Axis Product Comparison Table Autumn 2016 Axis Product Guide
Product Datasheets
Axis Q3515-LV 22mm Fixed Dome Network Camera 01044-001 Datasheet (0.46MB)
- HDTV 1080p video in full frame rate with Forensic WDR
- Lightfinder and OptimiserIR
- Axis Zipstream technology
- EIS, IK10 vandal resistance, IP52 water and dust protection
- Power with redundancy and configurable I/O ports
| Weight | 1400.000000 |
|---|---|
| Image chip size | 1/2.8" |
| Image chip type | Progressive Scan RGB CMOS |
| Image Compression | H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles Motion JPEG |
| Audio | Two-way |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 1 (0.44-3.84W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.03 |
| Supply Volts | 8-28V DC or PoE |
| Lens Mount | remote focus & zoom |
| Lens Focal Length | 9~22mm |
| Viewing Angle | 36° ~15° Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | P-Iris control |
| IR Range | Up to 60m |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 13.6W |
| Warranty | 3 Years |
| Launch Date | March 2018 |
