Geovision GV-BX12201 12MP Box Camera
The GV-BX12201 supports a range of features to improve security such as tampering alarm, focus change and camera shift. This camera also supports on board storage with a micro SD card slot and H.264 compression. The camera can be powered by a 12VDC power supply or PoE and remote access is possible through the GV-Eye app or through a web browser.
Quick Start GuideGeovision BrochureGeovision Mount Guide
Product Datasheets
GV-EYE app for mobile viewing
- H.264 or MJPEG
- 4000 x 3000 @ 15fps
- Built-in/external microphone
- Two-way audio
- One sensor input and alarm output
- TV-out support
- 12VDC/24VAC/PoE
- Built-in micro SD card slot
- Removable IR cut filter
- Wide dynamic range
- Low lux enhancement
- 3D noise reduction
- Smart streaming
- Defog
- Motion detection
- Tampering alarm
- 4.1mm ~ 9mm lens
- ONVIF compliancy
| Weight | 545.000000 |
|---|---|
| Image chip size | 1/1.7" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.264 & Motion JPEG |
| Audio | Two-way |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| Max. Resolution | 4000 X 3000 |
| Min. low-light lux | 0.05 |
| Supply Volts | 12V DC, 24V AC, PoE |
| Lens Mount | CS |
| Lens Focal Length | 4.1~9mm |
| Viewing Angle | 109° ~ 50° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 12 MP |
| Supplied with lens | Yes |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 6W |
| Warranty | 2 Years |
| Launch Date | September 2016 |
