Geovision GV-VD4702 4MP Vari-Focal Dome Camera
The GV-VD4702 has a 3-axis mechanism for precise set up ensuring any area of interest can be easily covered. This camera also supports two way audio for the connection of an external microphone and speaker. With a range of image enhancers such as wide dynamic range, back light compensation, 3D noise reduction and image configuration such as contrast, brightness and saturation, the GV-VD4702 can provide excellent video quality day or night. Security is further improved with the use of motion detection, tampering alarm and privacy mask.
This camera supports on board storage and H.265 compression meaning storage and bandwidth worries are a thing of the past. It can be powered by a 12VDC power supply or by PoE and remote access is possible through internet explorer or the GV-Eye app.
Vandal Resistant Dome Quick Start GuideGeovision BrochureGeovision Mount Guide
Product Datasheets
Geovision GV-VD4702 4MP Vari-Focal Dome Camera Datasheet (1.58MB)
GV-EYE app for mobile viewing
- Triple streams from H.265, H.264, MJPEG
- 20 fps @ 2592 x 1520
- 24 fps @ 2560 x 1440
- 30fps @ 2048 x 1520
- IK10 vandal resistant housing
- IP67 weatherproof housing
- P-iris lens for auto iris control
- Intelligent IR effective up to 30m
- 3-axis mechanism
- DC 12V/PoE
- Two-way audio
- Wide dynamic range
- 3D noise reduction technology
- Smart streaming
- Defog
- Motion detection
- Tampering alarm
- 31 languages on web interface
2.8mm - 12mm: Horizontal field of view: 102° to 36°
For help on figuring out which focal length is best for you please see here.
| Weight | 1150.000000 |
|---|---|
| Image chip size | 1/3" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Audio | Two-way |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP67 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| Max. Resolution | 2560 X 1440 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Lens Mount | Φ14 |
| Lens Focal Length | 2.8~12mm |
| Viewing Angle | 102° ~ 36° Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 4 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | P-Iris control |
| IR Range | Up to 30m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 9W |
| Warranty | 2 Years |
| Launch Date | Spring 2018 |
| Video |
