Hikvision DS-2CD2142FWD-I | 2.8mm 4MP WDR Fixed Dome Network Camera
The Hikvision DS-2CD2142FWD-I is a 4MP dome camera with the option of either a 2.8mm or 4mm lens. This camera is a great choice for external, domestic applications as it is fitted with IP66 rated weatherproof housing and IK10 vandal resistant housing. There are also built in infra-red LEDs that are effective up to 30m and help this camera to provide high quality images day and night.
The DS-2CD2142FWD-I has 3-axis adjustment allowing it to be mounted in versatile ways to ensure that any area of interest can be covered. There is also the optional choice of junction box or bracket to further expand the mounting options available to this camera. This camera uses a range of image enhancing features to improve image quality even further: wide dynamic range (WDR), back light compensation (BLC) and 3D digital noise reduction (3D DNR).
The DS-2CD2142FWD-I features a host of alarm trigger features such as motion detection, tampering alarm and many more. Using H.264+ codec, this camera is able to reduce bandwidth and storage needs allowing the on board micro SD card slot to be efficiently used. This dome camera can be powered by either a 12V DC power supply or by PoE. Remote access is possible through a web browser or through the Hik-Connect app.
Contact us for stock levels.
Hikvision Product Catalogue Hikvision Quick Guide Hikvision R6 Catalogue User Manual
Product Datasheets
Hikvision DS-2CD2142FWD-I | 2.8mm 4MP WDR Fixed Dome Network Camera Datasheet (0.84MB)
Useful Hikvision Tools
- SADP Download
- IE Tab Download
- Hik-Connect
- Up to 4 megapixel high resolution
- Full HD 1080p video
- Dual video streams
- 120dB wide dynamic range
- 3D digital noise reduction - 3-axis adjustment
- DC12V & PoE
- Support H264+
- IK10 protection
- Up to 30m IR range
- IP66 weatherproof protection
2.8mm - Horizontal field of view: 106°
4mm - Horizontal field of view: 83°
For help on figuring out which focal length is best for you please see here.
Lux Levels - For more information on Lux Levels please look here.
Hikvision IP Camera Codes
| Weight | 500.000000 |
|---|---|
| Image chip size | 1/2.8" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.264/MJPEG/H.264+ |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| Max. Resolution | 2688 X 1520 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Supply Volts | 12V DC or PoE |
| Lens Mount | M12 mount |
| Viewing Angle | Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 4 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | Yes |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 5W |
| Warranty | 2 Years |
| Launch Date | Autumn 2015 |
| Focal Length | 2.8mm |
| Audio/Alarm I/O | No Audio/Alarm I/O |
| Wireless | No Wireless |
