Milesight UI-5D63-PCV 5MP Mini Bullet Network Camera
With a unique housing design the Milesight UI-5D63-PCV mini bullet camera effectively blocks the sun from entering the lens path due to the sunshield almost encompassing the camera, not only this but the housing also offers thermal insulation and is IP67 weatherproof protecting the camera against harsh outdoor weather.
The camera's mounting bracket tightly conceals the cable to make sure it is well protected from dust, water and even shock damages as well as this the bracket has a 3-axis design to enable users to easily angle the camera to find the perfect spot for surveillance.
Other impressive features include; Super WDR (wide dynamic range) which is a sensor based technology used to balance out the colour representation in areas with extreme back light and high contrast conditions to produce true colour images and H.265+ video compression to reduce bandwidth by 70-80% compared to H.264.
Also included with this camera is VCA (video content analysis) which allows users access to even more advanced options such as; region entrance, region exiting, advanced motion detection, line crossing, loitering and people counting.
Focal length options are:
- 4mm ~ 62.8° FOV
- 6mm ~ 44° FOV
Included Accessories:
- Quick start guide
- Screws
- Rawl plugs
- Screwdriver
Milesight User ManualMilesight Product BrochureMilesight Product Catalogue
Product Datasheets
Milesight UI-5D63-PCV 5MP Mini Bullet Network Camera Datasheet (1.70MB)
- IP67 weather resistant housing
- 3-axis design
- MicroSD card slot
- IR LEDs effective up to 30m
- Video content analysis
- Built-in PoE module
| Weight | 820.000000 |
|---|---|
| Image chip size | 1/2.9" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.265+/H.265(HEVC)/H.264/MJPEG |
| Sensor | IMX326 |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP67 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| Max. Resolution | 2560 X 1920 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Supply Volts | POE only |
| Lens Mount | M12 mount |
| Aspect ratio | 16:9 |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | Yes |
| IR Range | Up to 30m |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 5W |
| Warranty | 3 Years |
| Launch Date | September 2017 |
| Video |
