Milesight UI-7032-B 32 Channel 4K Network Video Recorder
The Milesight UI-7032-B is a 32 channel NVR with H.264, H.265 and H.265+ video compression which can figure out and switch between codecs automatically. H.265+ compression reduces bandwidth by 70~80% compared to H.264, allowing users to get more out of their storage.
The NVR also has dual LAN interfaces for three network modes:
- Multi Address
Two Ethernet interfaces use different IP addresses and work separately in LAN1 and LAN2.
- Load Balance
Two Ethernet interfaces use the same IP address and share bandwidth of the system, aimed at increasing the throughput.
- Net Fault Tolerance
Two Ethernet interfaces use the same IP address. One main and one backup. If the main Ethernet interface is damaged it will switch over to the backup automatically.
Included Accessories:
- Quick start guide
- Mouse
- Screws
- Cables
- Rackmount ears
Milesight NVR User ManualMilesight Product BrochureMilesight Product Catalogue
Product Datasheets
Milesight UI-7032-B 32 Channel 4K Network Video Recorder Datasheet (1.39MB)
- Supports up to 32 IP cameras
- Audio I/O
- Alarm I/O
- HDMI and VGA Port
- 4 x SATA interfaces for up to 40TB of storage (Up to 10TB per HDD)
- RAID 0/1/5/10 supported
| Weight | 5000.000000 |
|---|---|
| Number of Channels | 32 |
| Synchronous Playback | 32-ch |
| Number of Bays | 4 |
| Alarm I/O | 16/4 |
| Front USB | 2 x USB 2.0 |
| Rear USB | 1 x USB 3.0 |
| Fan | Yes |
| RAID | Yes |
| RS232 | Yes |
| RS485 | Yes |
| Dual Lan | Yes |
| HDD Capacity Supplied | 0GB (Hard Disk Drives sold seperately to demand) |
| Maximum Memory Capacity | 40TB |
| Chassis | 1.5U |
| Dimensions | 440 x 320 x 66.8mm |
| Warranty | 3 Years |
| Launch Date | 2017 |
| Video |
