Vivotek CC8370-HV 3MP Anti-Ligature Fisheye Network Camera
With IP-66 rated housing this camera can be used outdoors or indoors and with a 180 degrees viewing angle and a 25 degrees tilt angle almost every area can be covered. The CC8370-HV utilizes Wide Dynamic Range and Supreme night Vision technology to provide security at all hours of the day no matter the light intensity.
Please note that this product may be subject to a 14-day lead time to fetch it from the manufacturer.
User Manual
Installation Guide
Product Datasheets
Vivotek CC8370-HV 3MP Anti-Ligature Fisheye Network Camera Datasheet (0.30MB)
- 30fps @ 2048x1536
- Anti-Ligature Design
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- 180° Horizontal Panoramic View ±25° Tilt Lens
- WDR Pro (100dB) to Provide Extreme Visibility in High Light Contrast Scenes
- Video Rotation
- Built-in Microphone
- SNV (Supreme Night Visibility)
- 3D Noise Reduction for Low-light Conditions
- Real-time H.264 and MJPEG Compression (Dual Codec)
- Built-in IEEE 802.3af Compliant PoE
- Built-in MicroSD/SDHC/SDXC card slot
Pack contents:
- CC8370-HV main unit
- Quick installation guide
- Warranty card
- Mounting bracket
- Screw pack
| Weight | 331.000000 |
|---|---|
| Image chip size | 1/3" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.264 & Motion JPEG |
| Audio | G.711/G.726 |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | Colour |
| POE built-in | Yes |
| POE Class | Class 1 (0.44-3.84W) |
| Max. Resolution | 2048 X 1536 |
| Min. low-light lux | 0.05 (IR LED ON) |
| Supply Volts | POE only |
| Lens Mount | fixed focus |
| Lens Focal Length | 1.6mm |
| Viewing Angle | 180˚ Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 3 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 4.9W |
| Warranty | 2 Years |
| Launch Date | Summer 2015 |
| Video | |
| Frames per Second | 8.3 fps |
| Resolution | 720p |
| Colour | White |
| Built-in PIR | No Built-in PIR |
