Vivotek FD8166A-N Ultra-mini Fixed Dome Network Camera
This camera can record at 30 fps with a 2MP full HD sensor. The image is enhanced and improved with the use of wide dynamic range and 3D noise reduction technology. With the use of Supreme Night Visibility and IR LEDs, the FD8166A-N can see up to 6M in complete darkness.
FD8166A-N User Manual
FD8166A-N Installation Guide
Product Datasheets
Vivotek FD8166A-N Ultra-mini Fixed Dome Network Camera Datasheet (0.38MB)
- 30 fps @ 1920x1080
- Real-time H.264 and MJPEG Compression (Dual Codec)
- SNV (Supreme Night Visibility) for Low Light Conditions
- Built-in 940nm Invisible IR Illuminators up to 6 M
- Smart IR Technology to Avoid Overexposure
- Smart Stream II to Optimize Bandwidth Efficiency
-WDR Enhanced
- 3D Noise Reduction
- Defog
- Built-in IEEE 802.3af Compliant PoE
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
- Compact and Stylish Design
- Easy Installation
- VIVOCloud Mobile App
Pack contents:
- FD8166A-N main unit
- Quick installation guide
- Warranty card
- Screws pack
- Focus kit
| Weight | 145.800000 |
|---|---|
| Image chip size | 1/2.8" |
| Image chip type | Progressive CMOS |
| Image Compression | H.264 & Motion JPEG |
| Audio | One way, built-in microphone |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 2 (3.84-6.49W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Lens Mount | fixed focus |
| Lens Focal Length | 2.8mm |
| Viewing Angle | Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| IR Range | Up to 5m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max 4.8W |
| Warranty | 2 Years |
| Launch Date | Spring 2017 |
| Video |
