Vivotek FD8167A 2MP Vari-Focal Indoor Dome Camera
If needed, the FD8167A has on-board storage meaning it can record strait to a MicroSD/SDHC/SDXC card. Powered by PoE, this camera utilises Vivotek's Smart Stream II technology to reduce the bandwidth usage whilst still delivering high quality images.
User Manual
Quick Installation Guide
Product Datasheets
Vivotek FD8167A 2MP Vari-Focal Indoor Dome Camera Datasheet (0.21MB)
- 30 fps @ 1920x1080
- Real-time H.264, MJPEG Compression (Dual Codec)
- Removable IR-cut Filter for Day & Night Function
- Built-in IR Illuminators, Effective up to 20 Meters
- Built-in 802.3af Compliant PoE
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
- Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
- SNV (Supreme Night Visibility)
- Smart Stream II to Optimize Bandwidth Efficiency
- 3D Noise Reduction
- Smart IR Technology to Avoid Overexposure
- VIVOCloud Mobile App
Horizontal field of view: 2.8mm - 12mm = 35°- 78°
For help on figuring out which focal length is best for you please see here.
| Weight | 416.400000 |
|---|---|
| Image chip size | 1/2.9" |
| Image chip type | Progressive CMOS |
| Image Compression | MJPEG & H.264 |
| Indoor / Outdoor | Indoors only |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.01 |
| Supply Volts | POE only |
| Lens Mount | vari-focal lens |
| Lens Focal Length | 2.8~12mm |
| Viewing Angle | 33.1°~96.6 Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | DC Iris |
| IR Range | Up to 20m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 8.5W |
| Warranty | 3 Years |
| Launch Date | Spring 2017 |
