Vivotek FD836BA-HVF2 2MP Fixed Dome Network Camera
With two-way audio, weather and vandal proof housing, the FD836BA-HVF2 is perfect for outdoor applications.
Quick Installation Guide
User Manual
Product Datasheets
Vivotek FD836BA-HVF2 2MP Fixed Dome Network Camera Datasheet (0.50MB)
- 30 fps @ 1920x1080
- 2.8 ~ 12 mm, Remote Focus, P-iris Lens
- Removable IR-cut Filter for Day & Night Function
- Built-in IR Illuminators, Effective up to 30 Meters
- Smart IR Technology to Avoid Overexposure
- WDR for Unparalleled Visibility in Extremely Bright and Dark Environments
- SNV (Supreme Night Visibility) for Low Light Conditions
- 3D Noise Reduction
- Two-way Audio
- Video Rotation for Corridor View
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Support Installation with AM-713 Outdoor Conduit Box
- Extreme Weather Support with PoE (FD836BA-EHTV/EHVF2)
- VIVOTEK VCA (Video Content Analysis) Support
Pack contents:
- Quick installation guide
- Warranty card
- Alignment sticker/desiccant bag
- Screw pack
- User's manual
- Quick installation guide
| Weight | 920.000000 |
|---|---|
| Image chip size | 1/2.7" |
| Image chip type | Progressive CMOS |
| Image Compression | H.264 & Motion JPEG |
| Audio | Two way, full duplex |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.01 |
| Lens Mount | fixed lens |
| Lens Focal Length | 2.8mm |
| Viewing Angle | Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| IR Range | Up to 30m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 9W |
| Warranty | 2 Years |
| Launch Date | Spring 2017 |
