Vivotek FD8382-ETV 5MP Vari-Focal Extreme Weather Dome Camera
This camera comes ready for changing environments, with wide dynamic range for improved visibility in bright and dark situations. The FD8382-ETV also benefits from video rotation through its corridor view.
User Manual
Quick Installation Guide
Product Datasheets
Vivotek FD8382-ETV 5MP Vari-Focal Extreme Weather Dome Camera Datasheet (0.22MB)
- 15 fps @ 2560x1920
- 3 ~ 9 mm, Remote Focus, P-iris Lens
- Built-in IR Illuminators, Effective up to 30 Meters
- WDR Enhanced for Unparalleled Visibility in Bright and Dark Environments
- Smart Stream to Optimize Bandwidth Efficiency
- 3D Noise Reduction
- Two-way Audio
- Video Rotation for Corridor View
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Support Installation with AM-713 Outdoor Conduit Box
- Extreme Weather Support with PoE
Horizontal field of view: 3mm - 9mm = 35°- 78°
For help on figuring out which focal length is best for you please see here.
| Weight | 920.000000 |
|---|---|
| Image chip size | 1/3.2" |
| Image chip type | CMOS |
| Image Compression | MJPEG & H.264 |
| Audio | Two way, full duplex |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| POE built-in | Yes |
| POE Class | Class 4 (12.95 - 25.50) |
| Max. Resolution | 2560 X 1920 |
| Supply Volts | 12V DC or PoE |
| Lens Mount | vari-focal lens |
| Lens Focal Length | 3~9mm |
| Viewing Angle | 35° ~ 78° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| IR Range | Up to 30m |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 25W |
| Warranty | 3 Years |
| Launch Date | Spring 2017 |
| Video |
