Vivotek FD8382-TV 5MP Fixed Dome Network Camera
This camera can be mounted in harsh outdoor conditions as it is armed with IP-66 rated weather-proof housing and IK-10 rated vandal proof housing.
Quick Installation Guide
User Manual
Product Datasheets
Vivotek FD8382-TV 5MP Fixed Dome Network Camera Datasheet (0.48MB)
- 15 fps @ 2560x1920
- 3 ~ 9 mm, Remote Focus, P-iris Lens
- Built-in IR Illuminators, Effective up to 30 Meters
- WDR Enhanced for Unparalleled Visibility in Bright and Dark Environments
- Smart Stream to Optimize Bandwidth Efficiency
- 3D Noise Reduction
- Two-way Audio
- Video Rotation for Corridor View
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Support Installation with AM-713 Outdoor Conduit Box
Pack contents:
- FD8382-TV main unit
- Quick installation guide
- Warranty card
- Alignment sticker/desiccant bag
- Screw pack
- User's manual CD
- Quick installation guide CD
| Weight | 920.000000 |
|---|---|
| Image chip size | 1/3.2" |
| Image chip type | Progressive CMOS |
| Image Compression | H.264 & Motion JPEG |
| Audio | Two way, full duplex |
| Auto-Focus | No |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 2560 X 1920 |
| Min. low-light lux | 0.001 |
| Lens Mount | vari-focal lens |
| Viewing Angle | 35° ~ 78° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max 9.5W |
| Warranty | 3 Years |
| Launch Date | Spring 2016 |
| Video | |
| Frames per Second | 8.3 fps |
| Resolution | 720p |
| Colour | White |
| Built-in PIR | No Built-in PIR |
