Vivotek FD9181-HT 5MP Indoor Fixed Dome Camera
Thanks to the built-in infra-red illuminators, this camera is able to capture images at up to 30m in the dark. In addition, it features a built-in PIR sensor to help detect any unexpected events and to provide real-time responses.
Quick Installation Guide
User Manual
Product Datasheets
Vivotek FD9181-HT 5MP Indoor Fixed Dome Camera Datasheet (0.41MB)
- 1/1.8" Progressive CMOS Sensor
- 30 fps @ 2560x1920, 60 fps @ 1920x1080
- Smart Stream II to Optimize Bandwidth Efficiency
- WDR Pro for Unparalleled Visibility in High Contrast Environments
- Built-in IR Illuminators, Effective up to 30 Meters
- Remote Focus for Easy Focus Adjustments
- SNV (Supreme Night Visibility) for Low Light Conditions
- PIR
- Video Rotation for Corridor View
- P-iris Lens
- DIS (Digital Image Stabilization)
Pack contents:
- FD9181-HT main unit
- Quick installation guide
- Screw pack
- Alignment sticker
- User's manual CD
- Quick installation guide CD
| Weight | 530.000000 |
|---|---|
| Image chip size | 1/1.8" |
| Image chip type | Progressive CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Audio | Two way, full duplex |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 2560 X 1920 |
| Min. low-light lux | 0.001 |
| Supply Volts | 12V DC or PoE |
| Lens Mount | vari-focal lens |
| Lens Focal Length | 4~9mm |
| Viewing Angle | 45° ~ 93° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | P-Iris control |
| IR Range | Up to 30m |
| Max. Images per second | 50 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 12.8W |
| Warranty | 3 Years |
| Launch Date | April 2017 |
| Video |
