Vivotek FD9371-EHTV 3MP Vari-Focal Dome Camera
The FD9371-EHTV benefits from a range of alarm and event triggers including motion detection, tampering detection and audio detection. By using H.265 compression you can capture quality images but use less storage space.
User Manual
Quick Installation Guide
Accessory Guide
Product Datasheets
Vivotek FD9371-EHTV 3MP Vari-Focal Dome Camera Datasheet (0.21MB)
- 1/2.8" Progressive CMOS Sensor
- 30 fps @ 2048x1536
- Smart Stream II to Optimize Bandwidth Efficiency
- WDR Pro for Unparalleled Visibility in High Contrast Environments
- Built-in IR Illuminators, Effective up to 30 Meters
- Remote Focus for Easy Focus Adjustments
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
- Extreme Weather Support with PoE
- SNV (Supreme Night Visibility) for Low Light Conditions
- Video Rotation for Corridor View
- P-iris Lens
- DIS (Digital Image Stabilization)
Pack Contents:
- FD9371-EHTV Main Unit x1
- User's Manual CD x1
- Quick installation guide
- Screw pack
- Alignment sticker
- Desiccant bag
- Water-proof connectors
Horizontal field of view: 3mm - 9mm = 41°- 86°
For help on figuring out which focal length is best for you please see here.
Weight | 928.000000 |
---|---|
Image chip size | 1/2.8" |
Image chip type | CMOS |
Image Compression | H.264/H.265/MJPEG |
Audio | Two way, full duplex |
Indoor / Outdoor | Indoors or Outdoors |
Ingress Protection | IP66 |
POE built-in | Yes |
POE Class | Class 4 (12.95 - 25.50) |
Max. Resolution | 2048 X 1536 |
Min. low-light lux | 0.001 |
Supply Volts | 12V DC or PoE |
Lens Mount | vari-focal lens |
Lens Focal Length | 3~9mm |
Viewing Angle | 41° ~ 86° Horizontal Field of View |
Aspect ratio | 4:3 |
Megapixels | 3 MP |
Supplied with lens | Yes |
Accepts auto-iris lens | P-Iris control |
IR Range | Up to 30m |
Max. Images per second | 30 |
PSU included | No |
ONVIF Compatible | Yes |
Warranty | 3 Years |
Launch Date | Spring 2017 |
Video |
