Vivotek FE9381-EHV 5MP Fisheye Camera
This versatile camera can be used in a wide range of applications both indoors and outdoors and thanks to its 180° panoramic view (wall mount) or 360° surround view (ceiling/floor mount) it has zero blind spots, making it perfect to provide coverage of wide open areas, such as airports, shopping malls, retail stores and offices.
Quick Installation Guide
User Manual
Accessory Manual
Product Datasheets
- 5-Megapixel CMOS Sensor
- 30 fps @ 1920x1920
- 1.47 mm Fisheye Lens for 180° Panoramic View and 360° Surround View
- Removable IR-cut Filter for Day & Night Function
- WDR Pro for Unparalleled Visibility in High Contrast Environments
- Smart Stream II to Optimize Bandwidth Efficiency
- EN50155 Compliance for Professional Mobile Surveillance
- Vandal-proof IK10-rated and Weather-proof IP66-rated Housing
- ePTZ for Data Efficiency
- Built-in 802.3af Compliant PoE
- Support Client Side Dewarping
- Pixel Calculator for Image Clarity Measurement
Pack contents:
- Quick installation guide
- Warranty card
- Alignment sticker
- Desiccant bag
- Screw driver
- Screws pack
- I/O cable
- Mounting bracket
- Software CD
| Weight | 548.000000 |
|---|---|
| Image chip size | 1/1.8" |
| Image chip type | Progressive CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Audio | Two way, full duplex |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 1920 X 1920 |
| Min. low-light lux | 0.001 |
| Supply Volts | 12V DC or PoE |
| Lens Mount | fixed focus |
| Lens Focal Length | 1.47mm |
| Viewing Angle | 180° Horizontal Field of View |
| Aspect ratio | N/A |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| Max. Images per second | 25 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 13W |
| Warranty | 3 Years |
| Launch Date | April 2017 |
| Video |
