Vivotek IB8369A 2MP Bullet Network Camera
The IB8369A uses a removable IR-cut filter and IR LEDs to record up to 30M in the dark giving you security in changing lighting conditions.
IB8369A Installation Guide
V-Pro Lite Line
IB8396A User Manual
Product Datasheets
Vivotek IB8369A 2MP Bullet Network Camera Datasheet (0.50MB)
- 30 fps @ 1920x1080
- Real-time H.264, MJPEG Compression (Dual Codec)
- Removable IR-cut Filter for Day & Night Function
- Built-in IR Illuminators, Effective up to 30 Meters
- Built-in 802.3af Compliant PoE
- Built-in MicroSD/SDHC/SDXC Card Slot for On-board Storage
- Supports ONVIF Standard to Simplify Integration and Enhance Interoperability
- Weather-proof IP66-rated and Vandal-proof IK10-rated Metal Housing
- Smart Stream II to Optimize Bandwidth Efficiency
- 3D Noise Reduction
- Smart IR Technology to Avoid Overexposure
- SNV (Supreme Night Visibility) for Low Light Conditions
- VIVOCloud Mobile App
Pack contents:
- IB8369A main unit
- Quick installation guide
- Alignment sticker
- Cable management bracket
- Screw pack
- Sun shield
| Weight | 1010.000000 |
|---|---|
| Image chip size | 1/2.9" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.264 & Motion JPEG |
| Auto-Focus | No |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 0 (0.44-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0.01 |
| Lens Mount | fixed focus |
| Lens Focal Length | 3.6mm |
| Viewing Angle | 78° Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| IR Range | Up to 30m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 10W |
| Warranty | 2 Years |
| Launch Date | Spring 2016 |
| Video | |
| Frames per Second | 8.3 fps |
| Resolution | 720p |
| Colour | White |
| Built-in PIR | No Built-in PIR |
