Vivotek IB9391-EHT 8MP Vari-focal Outdoor Bullet Camera
The Vivotek IB9391-EHT is suitable for use both indoors and outdoors thanks to its IP67 weatherproof-rated and IK10 vandal resistance-rated housing. In addition it can be used in extreme weather conditions of temperatures from -50°C to 60°C.
User Manual
Quick Installation Guide
Accessory Chart
Product Datasheets
Vivotek IB9391-EHT 8MP Vari-focal Outdoor Bullet Camera Datasheet (0.31MB)
- 30 fps @ 3840x2160 (WDR Pro on)
- 120 fps @ 1920x1080 (WDR Pro off)
- Smart Stream III to Optimize Bandwidth Efficiency
- Built-in IR Illuminators, Effective up to 50 Meters
- Smart IR II Technology to Avoid Overexposure
- WDR Pro for Unparalleled Visibility in Extremely Bright and Dark Environments
- SNV (Supreme Night Visibility) for Low Light Conditions
- Weather-proof IP66, IP67 rated, Vandal-proof IK10-rated Housing
- -50°C ~ 60°C Wide Temperature Range for Extreme Weather Conditions (IR Off)
3.9mm - 10mm: Horizontal field of view: 95° to 45°
For help on figuring out which focal length is best for you please see here.
Weight | 1755.000000 |
---|---|
Image chip size | 1/2" |
Image chip type | Progressive CMOS |
Image Compression | H.264/H.265/MJPEG |
Audio | Bi-directional speak/listen |
Indoor / Outdoor | Indoors or Outdoors |
Ingress Protection | IP67 |
POE built-in | Yes |
POE Class | Class 4 (12.95 - 25.50) |
Max. Resolution | 3840 X 2160 |
Min. low-light lux | 0 Lux (IR LED ON) |
Supply Volts | 12V DC, 24V AC or PoE |
Lens Mount | vari-focal lens |
Lens Focal Length | 3.9~10mm |
Viewing Angle | 45° ~ 95° Horizontal Field of View |
Aspect ratio | 16:9 |
Megapixels | 8 MP |
Supplied with lens | Yes |
IR Range | Up to 50m |
Max. Images per second | 120 |
PSU included | No |
ONVIF Compatible | Yes |
Power Consumption | max. 25W |
Warranty | 3 Years |
Launch Date | Summer 2018 |
Video |
