Vivotek MS9390-HV Multi-Sensor 8MP Dome Camera
This camera can capture up to 30fps and its built-in infra-red illuminators allow it to continue capturing 180° footage up to 20m in the dark, making it a 24/7 solution. The MS9390-HV also benefits from an IP66 weatherproof-rated and IK10 vandal resistant-rated housing meaning it can be used both indoors and outdoors.
The MS9390-HV comes with a sunshield included and doesn't need any other accessories as it can be mounted directly on to a wall thanks to its 20° of internal tilt adjustment which allows users to get the exact angle that they desire.
User Manual
Quick Installation Guide
Product Datasheets
Vivotek MS9390-HV Multi-Sensor 8MP Dome Camera Datasheet (0.34MB)
- H.265 Compression Technology
- 180° Panoramic View
- 30 fps @ 4512x1728
- Video Alignment For a Seamless Image
- Smart Stream III to Optimize Bandwidth Efficiency
- Built-in IR Illuminators, Effective up to 20 Meters
- SNV (Supreme Night Visibility)
- 3D Noise Reduction for Low-light Conditions
- Built-in Microphone
- Built-in MicroSD/SDHC/SDXC Card Slot
- Weather-proof IP66-rated and Vandal-proof IK10-rated Housing
| Weight | 1207.000000 |
|---|---|
| Image chip size | 1/2.7" |
| Image chip type | Progressive CMOS |
| Image Compression | H.264/H.265/MJPEG |
| Audio | One way, built-in microphone |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| POE built-in | Yes |
| POE Class | Class 4 (12.95 - 25.50) |
| Max. Resolution | 4512 x 1728 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Supply Volts | POE only |
| Lens Mount | fixed focus |
| Lens Focal Length | 2.8mm |
| Viewing Angle | 180° Horizontal Field of View |
| Aspect ratio | N/A |
| Megapixels | 8 MP |
| Supplied with lens | Yes |
| IR Range | Up to 20m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max 15.2W |
| Warranty | 3 Years |
| Launch Date | Spring 2018 |
