Wisenet QND-6010R/QND-6020R/QND-6030R | 2MP Full HD IR Dome Camera
- QND-6010R = 2.8mm lens
- QND-6020R = 3.6mm lens
- QND-6030R = 6mm lens
Each camera uses smart features such as motion detection and defocus detection to ensure that your security needs are fulfilled.
Accessory ChartUser ManualH.265 BrochureQ Series Brochure
Product Datasheets
Wisenet QND-6010R/QND-6020R/QND-6030R | 2MP Full HD IR Dome Camera Datasheet (0.19MB)
- Max. 30fps@all resolutions (H.265/H.264)
- H.265, H.264, MJPEG codec supported, Multiple streaming
- Motion detection, Tampering, Defocus detection
- micro SD (128GB) memory slot, PoE / 12V DC
- IR viewable length 20m, IK08
- Hallway view, WiseStream support
- LDC support (Lens Distortion Correction)
QND-6010R - Horizontal field of view: 110°
QND-6020R - Horizontal field of view: 86.48°
QND-6030R - Horizontal field of view: 52.54°
For help on figuring out which focal length is best for you please see here.
| Weight | 290.000000 |
|---|---|
| Image chip size | 1/2.9" |
| Image chip type | CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Audio | One way, built-in microphone |
| Indoor / Outdoor | Indoors only |
| Colour / monochrome | Colour/Mono switching |
| POE built-in | Yes |
| POE Class | Class 3 (6.49-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Lens Mount | fixed lens |
| Viewing Angle | Horizontal Field of View |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| IR Range | Up to 20m |
| Max. Images per second | 30 |
| PSU included | Yes |
| ONVIF Compatible | Yes |
| Warranty | 1 Year |
| Launch Date | Autumn 2016 |
| Video | |
| Audio/Alarm I/O | Audio/Alarm I/O |
| Wireless | Wireless |
| Frames per Second | 8.3 fps |
