Wisenet QNV-6010R/QNV-6020R/QNV-6030R | 2MP Vandal-Resistant IR Dome Camera
- QNV-6010R = 2.8mm lens - 20m IR
- QNV-6020R = 3.6mm lens - 25m IR
- QNV-6030R = 6mm lens - 30m IR
With the ability to record at 30fps and H.265 codec, a high quality image is guaranteed. These cameras use many smart features such as motion detection and defocus detection to provide security at all hours. Each camera is protected by IK10 rated vandal proof housing and IP66 rated weatherproof housing so they can be mounted outdoors with no worry.
Accessory ChartUser ManualH.265 BrochureQ Series Brochure
Product Datasheets
Wisenet QNV-6010R/QNV-6020R/QNV-6030R | 2MP Vandal-Resistant IR Dome Camera Datasheet (0.14MB)
- Max. 30fps@all resolutions (H.265/H.264)
- H.265, H.264, MJPEG codec supported, Multiple streaming
- Motion detection, Tampering, Defocus detection
- micro SD (128GB) memory slot, PoE / 12V DC
- IR viewable length 20m (QNV-6010R), 25m (QNV-6020R) 30m (QNV-6030R)
- Hallway view, WiseStream support, IP66, IK10
- LDC support (Lens Distortion Correction)
QNV-6010R - Horizontal field of view: 110°
QNV-6020R - Horizontal field of view: 86.48°
QNV-6030R - Horizontal field of view: 52.54°
For help on figuring out which focal length is best for you please see here.
| Weight | 490.000000 |
|---|---|
| Image chip size | 1/2.9" |
| Image chip type | Progressive CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Auto-Focus | No |
| Indoor / Outdoor | Indoors or Outdoors |
| Ingress Protection | IP66 |
| Colour / monochrome | True Day/Night |
| POE built-in | Yes |
| POE Class | Class 3 (6.49-12.95W) |
| Max. Resolution | 1920 X 1080 |
| Min. low-light lux | 0 Lux (IR LED ON) |
| Lens Mount | board-in type |
| Aspect ratio | 16:9 |
| Megapixels | 2 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | No |
| Max. Images per second | 30 |
| PSU included | Yes |
| ONVIF Compatible | Yes |
| Warranty | 2 Years |
| Launch Date | Autumn 2016 |
