Geovision GV-VD5700 5MP Vari-Focal Dome Camera
The GV-VD5700 supports two way audio and uses a range of image enhancers to improve security further: backlight compensation, wide dynamic range, defog, low lux enhancement and denoise. This camera also uses some smart features for further support such as tampering alarm, focus change and camera shift.
There is also a built-in micro SD card slot and with the use of H.265 compression, bandwidth and storage concerns are greatly reduced. The GV-VD5700 can be powered by a power supply or by a PoE injector. Remote access is possible through the GV-Eye app or by a web browser.
Vandal Resistant Dome Quick Start GuideGeovision BrochureGeovision Mount Guide
Product Datasheets
Geovision GV-VD5700 5MP Vari-Focal Dome Camera Datasheet (1.27MB)
GV-EYE app for mobile viewing
- 2.8mm~12mm vari focal lens
- H.265, H.264, MJPEG
- Up to 30fps
- P-Iris
- IK10 vandal resistant
- IP67 weatherproof
- Intelligent IR up to 30m
- Two-way audio
- Micro SD card slot
- 12VDC/PoE
- WDR Pro
- Smart streaming
- Defog
- Text overlay
- Tampering alarm
- 3D noise reduction technology
- ONVIF compliant
2.8mm - 12mm: Horizontal field of view: 88° to 51°
For help on figuring out which focal length is best for you please see here.
| Weight | 800.000000 |
|---|---|
| Image chip size | 1/1.8" |
| Image chip type | Progressive Scan CMOS |
| Image Compression | H.265,H.264,MJPEG |
| Audio | Two-way |
| Auto-Focus | No |
| Indoor / Outdoor | Outdoor |
| Ingress Protection | IP67 |
| Colour / monochrome | Colour/Mono switching |
| POE built-in | Yes |
| Max. Resolution | 2592 X 1944 |
| Min. low-light lux | 0.04 |
| Supply Volts | 12V DC or PoE |
| Lens Mount | Φ14 |
| Lens Focal Length | 4~8mm |
| Viewing Angle | 88°~51° Horizontal Field of View |
| Aspect ratio | 4:3 |
| Megapixels | 5 MP |
| Supplied with lens | Yes |
| Accepts auto-iris lens | P-Iris control |
| IR Range | Up to 30m |
| Max. Images per second | 30 |
| PSU included | No |
| ONVIF Compatible | Yes |
| Power Consumption | max. 12.6W |
| Warranty | 2 Years |
| Launch Date | October 2016 |
| Video | |
| Audio/Alarm I/O | Audio/Alarm I/O |
| Wireless | No Wireless |
| Frames per Second | 30 fps |
| Colour | White |
| Built-in PIR | Built-in PIR |
