Hikvision DS-7616NI-I2-16P 16 Channel Network Video Recorder
The Hikvision DS-7616NI-I2/16P is a 16 channel network video recorder with 16 built-in PoE ports for plug and play systems. This NVR has two spaces for hard drives and can hold 20TB of storage.
With the help of H.265+ compression, the DS-7616NI-I2/16P supports IP cameras up to 12MP. There are HDMI and VGA outputs so monitors can be easily connected, alternatively, the NVR can be accessed remotely through a browser or through the Hik-Connect app.
This NVR will accept any capacity hard drive (HDD) currently available. Any maximum capacity stated on the manufacturer’s documents is simply based upon the maximum HDD size that was available at the time of release/publication
The DS-7616NI-I2/8P is ready for Hikvision's Automatic Number Plate Recognition Cameras (ANPR) and supports two way audio among other features. A power supply is included with this.
Max. HDD support ~ 20TB (2 x 10TB)
Max: supported IP cameras ~ 16
Max: Megabits per second (Mbps) ~ 160
Please note that Hikvision NVRs are supplied without hard drives. We recommend the WD Purple HDDs for this product.
Hikvision NVR User Manual Hikvision NVR Quick Start Guide Hikvision Product Catalogue Hikvision Quick Guide
Product Datasheets
Hikvision DS-7616NI-I2-16P 16 Channel Network Video Recorder Datasheet (0.55MB)
Breaking News Friday 10th November: HikVision have released a significant V4 firmware update for -I NVRs. It is not yet clear whether -K NVRs will also receive this update. For further information & updates please click here
Useful Hikvision Tools
- SADP Download
- IE Tab Download
- Hik-Connect
- Dual-OS design to ensure high reliability of system running
- H.265+/H.265/H.264+/H.264/MPEG-4 formats
- Up to 16 IP cameras can be connected
- HDMI and VGA outputs provided
- Up to 2 SATA interfaces for max 2 x 10TB
- 16 PoE network interfaces
| Weight | 3000.000000 |
|---|---|
| Number of Channels | 16 |
| Synchronous Playback | 16-ch |
| Number of PoE Ports | 16 |
| Incoming Bandwidth | 160 Mbps |
| Outgoing Bandwidth | 256 Mbps |
| Number of Bays | 2 |
| Audio Input | 1-ch |
| Audio Ouput | 1-ch |
| Alarm I/O | 4/1 |
| Front USB | 1 x USB 2.0 |
| Rear USB | 1 x USB 3.0 |
| Fan | Yes |
| RAID | No |
| ANR (Automatic Network Recover) | Yes |
| Maximum Memory Capacity | 20TB |
| Chassis | 380mm |
| Dimensions | 380 x 290 x 45mm |
| Warranty | 3 Years |
| Launch Date | 2016 |
| Video |
